Items

Specification

POL.12.500T

POL.12.500R

POL.12.500TR

Transmitted

Reflected

Transmitted & Reflected

Eyepiece

WF10×-18mm

●

●

WF10×-18 mm (Reticule 0.1mm)

●

●

WF10×-20 mm

●

WF10×-20 mm (Reticule 0.1mm)

●

Non-stress
Infinity
Plan Objective

4×/0.10

●

●

●

10×/0.25

●

●

●

20×/0.40(S)

●

●

●

40×/0.65(S) (0.17mm cover glass)

●

●

40×/0.65S) (no cover glass)

●

○

60×/0.80 (S)

○

○

●

LWD Infinity Plan Objective
(no cover glass)

20×/0.40 (S)      W.D=8.35mm

○

○

40×/0.65 (S)      W.D=3.90mm

○

○

50×/0.70 (S)      W.D=1.95mm

○

○

80×/0.80 (S)    W.D=0.85mm

○

○

Seidentopf Binocular Head

Inclined 30°, Rotatable 360°,
Interpupilary Distance:  50-75mm.

●

●

●

Seidentopf Trinocular Head

Inclined 30°, Rotatable 360°,
Interpupilary Distance:  50-75mm.
Light Distribution: 0:100

○

○

○

Professional dedicated polarizing binocular head

It can keep the cross in the right-hand eyepiece always same when the eyepiece tubes turned.

○

○

○

Professional dedicated polarizing trinocular head

○

○

○

Nosepiece

Quintuple

●

●

●

Analyzer Unit with Scale

Rotatable 360°(Module Type, Can Be Locked)

●

●

●

Bertrand Lens

Built In, Center Adjustable

●

●

●

Λ Slip

First Class Red

●

●

●

1/4λ Slip

●

●

●

Quartz Wedge

(Ⅰ-Ⅳ Class)

●

●

●

Revolving Round Stage

Stage Dia: 156,mm
Rotatable 360°, Center Adjustable,
Division 1°, Vernier Division 6’
Hole Diameter for Condenser:26mm

●

●

●

Polarizing Attached Mechanical Stage

○

○

○

Swing-out Condenser

N.A.0.9/0.13 swing out achromatic condenser

●

●

Polarizing Unit with Scale

Rotatable 360°,Can Be Locked

●

●

Koehler Illumination

6V/20W Halogen Lamp
(6V/30W is Optional)

●

●

Filter

Blue

●

●

●

Amber

○

○

○

Green

○

○

○

Neutral

○

○

○

Reflecting Polarizing Unit

Halogen Lamp House 12V/50W

●

●

Power House

●

●

Polarizer Choosing Slide

●

●

C-mount

1×

○

○

○

0.57× （Focus adjustable）

○

○

○
